DAIKIN DX type 40 MPa Distributing Valve
This distributing valve supports an ultrahigh pressure of 40 MPa, and can beswitched between single and doubledischarge.\
Overview
The DX distributing valve supports ultra-high pressure of 40MPa, and can be switched between single and double discharge.
Features
Max. Operating Pressure 40 MPa
Pistons finished with high precision and the solid body of thisdistributing valve allow it to be used up to ultra-high pressure of40 MPa and grease to be supplied to an even wider area. Thisalso reduces the restrictions placed on enyironmentatemperature and grease
Outstanding Heat Resistance
The distributing valve can be used in locations where heat resistance is reguired since fluorinated rubber is used on all seal packings
Single and Double Discharge Can Be changed
The discharge type, single or double, can be changed independently for all elements. This results in double the discharge in the case osingle discharge. Using the plug hole at the front top as the upper discharging port will make it easier to check pointer operation.
